19'' Rack Flightcase
400amp | Heights 20U, 21U, 24U
19'' Rack Flightcase
400amp | Heights 20U, 21U, 24U
Refined in the smallest details:
color of plugs and sockets, identification labels,
accuracy in the design and the accessories.
-
400 Amp
400 Amp
19'' Rack Flightcase 24U
19'' Rack Flightcase 24U
Part Number: PBF400P24U-40064S11L
-
Front 1 voltmeter selector switch with analogic voltmeter + 1 set incoming leds 1 MCCB 400amp 4p 36.000A (MAIN) + 1 shunt release + 1 E-STOP 1 digital multimeter 96x96mm with LCD graphic display 6 x RCBO 16amp 1pN-C 6.000/10.000A Idn=0,03A AC (6 x CEE-17 16amp 3p) 72 x RCBO 16amp 1pN-C 6.000/10.000A Idn=30mA AC (12 x SYNTAX® SSX 19-pin) 4 x MCB 32amp 3pN-C 6.000/10.000A with earth leakage add-on block Idn=30mA AC (4 x CEE-17 32amp 5p) 1 MCB 63amp 4p-C 6.000/10.000A with earth leakage add-on block Idn=300mA AC (1 CEE-17 63amp 5p) 1 MCB 125amp 4p-C 10.000A with earth leakage add-on block Idn=300mA AC (1 CEE-17 125amp 5p) Rear 5 x powerSYNTAX® 480amp L1-brown L2-black L3-grey N-blue PE-green 400V IP67 (IN ; power-lock compatible) 5 x powerSYNTAX® 480amp L1-brown L2-black L3-grey N-blue PE-green 400V IP67 with IP67 caps (LOOP ; powerlock compatible) 6 x CEE-17 16amp 3p 230V IP44 (OUT) 12 x SYNTAX® SSX 19p IP67 (OUT; Socapex 419 compatible) 4 x CEE-17 32amp 5p 400V IP44 (OUT) 1 CEE-17 63amp 5p 400V IP67 (OUT) 1 CEE-17 125amp 5p 400V IP67 (OUT) Nominal data CE Marking, IEC 61439-1 & 2 / PSC, Un : 400V 3pH+N+PE, fn : 50Hz, InA : 400amp, Icc : 10.000A, RDF : 50/100, IP : 44, Electrical insulation class : I (first) -
Rear
Rear
-
Front
Front
-
-
400Amp
400Amp
19'' Rack Flightcase 21U
19'' Rack Flightcase 21U
Part Number: PBF400P21U-25403
Front 1 voltmeter selector switch with analogic voltmeter + 1 set incoming leds 1 MCCB 400amp 4p 36.000A (MAIN) + 1 shunt release + 1 E-STOP 1 digital multimeter 96x96mm with LCD graphic display 6 x RCBO 16amp 1pN-C 6.000/10.000A Idn=0,03A AC (6 x CEE-17 16amp 3p) 2 x MCB 32amp 4p-C 6.000/10.000A with earth leakage add-on block Idn=30mA AC (2 x CEE-17 32amp 5p) 2 x MCB 63amp 4p-C 6.000/10.000A with earth leakage add-on block Idn=300mA AC (2 x CEE-17 63amp 5p) 2 x MCB 125amp 4p-C 10.000A with earth leakage add-on block Idn=300mA AC (2 x CEE-17 125amp 5p). Rear 2 x 5 x powerSYNTAX® 480amp L1-brown L2-black L3-grey N-blue PE-green 400V IP67 (IN ; powerlock compatible) 2 x 5 x powerSYNTAX® 480amp L1-brown L2-black L3-grey N-blue PE-green 400V IP67 with IP67 caps (LOOP ; powerlock compatible) 6 x CEE-17 16amp 3p 230V IP44 (OUT) 2 x CEE-17 32amp 5p 400V IP44 (OUT) 2 x CEE-17 63amp 5p 400V IP67 (OUT) 2 x CEE-17 125amp 5p 400V IP67 (OUT) Technical data CE Marking, IEC 61439-1 & 2 / PSC, Un : 400V 3pH+N+PE, fn : 50Hz, InA : 400amp, Icc : 6.000A, RDF : 33/100, IP : 44, Electrical insulation class : I (first) -
Rear
Rear
-
Front
Front
-
400Amp
400Amp
19'' Rack Flightcase 20U
19'' Rack Flightcase 20U
Part Number: PBF400P20U-31734
Front 1 voltmeter selector switch with analogic voltmeter + 1 set incoming leds 1 MCCB 400amp 4p 36.000A (MAIN) + 1 shunt release + 1 E-STOP 1 digital multimeter 96x96mm with LCD graphic display 1 MCB 16amp 4p-D 10.000A + 3 x RCBO 16amp 1pN-B 6.000A Idn=0,03A AC (3 x CEE-17 16amp 3p) 1 MCB 32amp 4p-D 10.000A with earth leakage add-on block Idn=30mA AC (1 CEE-17 32amp 5p) 7 x MCB 63amp 4p-D 10.000A with earth leakage add-on block Idn=300mA AC selective (7 x CEE-17 63amp 5p) 1 modular surge arrester with Advanced Circuit Interruption (ACI) type 2 / class II Rear 5 x powerSYNTAX® 480amp L1-brown L2-black L3-grey N-blue PE-green 400V IP67 (IN ; powerlock compatible) 3 x CEE-17 16amp 3p 230V IP67 (OUT) 1 CEE-17 32amp 5p 400V IP67 (OUT) 7 x CEE-17 63amp 5p 400V IP67 (OUT) Technical data CE Marking, IEC 61439-1 & 2 / PSC, Un : 400V 3pH+N+PE, fn : 50Hz, InA : 400amp, Icc : 10.000A, RDF : 81/100, IP : 55, Electrical insulation class : I (first)
-
Rear
Rear
-
Front
Front
-
400Amp
400Amp
19'' Rack Flightcase 20U
19'' Rack Flightcase 20U
Part Number: PBF400P20U-29302
Front 1 voltmeter selector switch with analogic voltmeter + 1 set incoming leds 1 MCCB 400amp 4p 36.000A (MAIN) + 1 shunt release + 1 E-STOP 1 digital multimeter 96x96mm with LCD graphic display 96 x RCBO 16amp 1pN-C 6.000/10.000A Idn=30mA AC (16 x SYNTAX® SSX 19-pin) Rear 5 x powerSYNTAX® 480amp L1-brown L2-black L3-grey N-blue PE-green 400V IP67 (IN ; powerlock compatible) 16 x SYNTAX® SSX 19-pin IP67 (OUT; Socapex 419 compatible) Technical data CE Marking, IEC 61439-1 & 2 / PSC, Un : 400V 3pH+N+PE, fn : 50Hz, InA : 400amp, Icc : 6.000A, RDF : 78/100, IP : 44, Electrical insulation class : I (first)
-
Rear
Rear
-
Front
Front
-
-
400 Amp
400 Amp
19'' Rack Flightcase 20U
19'' Rack Flightcase 20U
Part Number: PBF400P20U-400319L
-
Front 1 voltmeter selector switch with analogic voltmeter + 1 set incoming leds 1 MCCB 400amp 4p 36.000A (MAIN) + 1 shunt release + 1 E-STOP 1 digital multimeter 96x96mm with LCD graphic display 3 x RCBO 16amp 1pN-C 6.000/10.000A Idn=0,03A AC (3 x CEE-17 16amp 3p) 1 MCB 32amp 4p-C 6.000/10.000A with earth leakage add-on block Idn=30mA AC (1 CEE-17 32amp 5p) 9 x MCB 63amp 4p-C 6.000/10.000A with earth leakage add-on block Idn=300mA AC (9 x CEE-17 63amp 5p). Rear 5 x powerSYNTAX® 480amp L1-brown L2-black L3-grey N-blue PE-green 400V IP67 (IN ; powerlock compatible) 5 x powerSYNTAX® 480amp L1-brown L2-black L3-grey N-blue PE-green 400V IP67 with IP67 caps (LOOP ; powerlock compatible) 3 x CEE-17 16amp 3p 230V IP44 (OUT) 1 CEE-17 32amp 5p 400V IP44 (OUT) 9 x CEE-17 63amp 5p 400V IP67 (OUT) Technical data CE Marking, IEC 61439-1 & 2 / PSC, Un : 400V 3pH+N+PE, fn : 50Hz, InA : 400amp, Icc : 6.000A, RDF : 50/100, IP : 44, Electrical insulation class : I (first) -
Rear
Rear
-
Front
Front
