Power in a steel suit. Perfect for large-sized power supply to be set up in a short time, PowerBox Heavy-Duty distros are specifically suited for harsh work environments and outdoor applications.

  • Working in tough conditions?
    Here is the distro for you

    Working in tough conditions?
    Here is the distro for you

    Strong, customizable and easily movable

    Strong, customizable and easily movable

    The PowerBox Heavy Duty distros are resistant and strong, so they are especially suited for broadcasting, sport events, fairs and any kind of outdoor applications. They are easy to move as the structure is designed to be stackable and allows usage of forklift or lifting cables. All components are fitted with screws resistant to vibrations, shocks and all forms of mechanical stress they might be exposed to, in order to ensure maximum safety over time. All the designs can be customized to the smallest detail: input and outputs, switches, protection devices, displays, connectors' colors etc. From 16 to 400 Amp or even higher current ratings, and several operating voltage options.



  • Easy is the word

    Easy is the word

    PowerBox distros are designed with a special eye on the operators

    PowerBox distros are designed
    with a special eye on the operators

    Easy to put into operation, as inputs and outputs all are quick-type plugs, sockets and connectors, with no special tools needed. Easy everyday usage as all plugs, sockets, connectors and therefore cables are on the same side, while protections, displays and switches are all placed on the front side to be easily accessible to the operator. Care for details and thoughtful layout focused on ergonomics, with the bigger connectors always placed in the lower part of the panel, making it easier for the operators to plug and unplug even the heaviest cables.

  • Discover our popular solutions

    Discover our popular solutions

    Discover
    our popular solutions

    Or contact us to discuss a custom layout together

    Or contact us to discuss a
    custom layout together

    We know every job has its peculiar requirements and a few default products cannot fulfill everybody's needs. That's why we made customization the cornerstone of our work. Here we present some of our most successful Heavy-duty series layouts for you to choose or take inspiration from in order to design your perfect configuration.

  • 400 Amp

    400 Amp

    Heavy Duty 2x12U

    Heavy Duty 2x12U

    Part Number: PBF400P212U-160

    400 Amp
  • Front1 set incoming leds
    1 MCCB 160amp 4p 18.000A (MAIN OUT) + 1 shunt release + 1 E-STOP pull to release
    1 digital multimeter with LCD graphic display
    2 x MCB 100amp 4p-C 10.000A with earth-leakage relay (adjustable fault current and delay time) + 6 x MCB 32amp 4p-C 6.000/10.000A (6 x CEE-17 32amp 5p)
    1 MCB 100amp 4p-C 10.000A with earth-leakage relay (adjustable fault current and delay time) + 1 MCB 63amp 4p-C 6.000/10.000A (CEE-17 63amp 5p) + 1 MCB 80amp 4p-C 10.000A (Marechal DS6 90amp 5p)

    Rear5 x powerSYNTAX® 480amp L1-brown L2-black L3-grey N-blue PE-green 400V IP67 (IN ; power-lock 400A compatible)
    5 x powerSYNTAX® 480amp L1-brown L2-black L3-grey N-blue PE-green 400V IP67 with IP53 caps (LOOP ; powerlock 400A compatible)
    6 x CEE-17 32amp 5p 400V IP67 (OUT)
    1 CEE-17 32amp 5p 400V IP67 (OUT)
    1 Marechal DS6 90amp 5p IP65 (OUT)

    Technical dataCE Marking, IEC 61439-1 & 2 / PSC, Un : 400V 3pH+N+PE, fn : 50Hz, InA : 400amp (IN), InA : 160A (Main OUT), Icc : 10.000A, RDF : 71/100, IP : 54, Electrical insulation class : I (first).

  • Rear

    Rear

    Rear

  • Front

    Front

    Front

  • 400 Amp

    400 Amp

    Heavy Duty 2x24U

    Heavy Duty 2x24U

    Part Number: PBF400P224U-400

    400 Amp
  • Front1 set incoming leds
    1 MCCB 400amp 4p 36.000A (MAIN OUT CEE-17 32amp, 63amp and DS6) + 1 shunt release + 1 E-STOP pull to release
    1 digital multimeter with LCD graphic display
    3 x MCB 100amp 4p-C 10.000A with earth-leakage relay (adjustable fault current and delay time) + 9 x MCB 32amp 4p-C 6.000/10.000A (9 x CEE-17 32amp 5p)
    2 x MCB 100amp 4p-C 10.000A with earth-leakage relay (adjustable fault current and delay time) + 2 x MCB 63amp 4p-C 6.000/10.000A (2 x CEE-17 63amp 5p) + 2 x MCB 80amp 4p-C 10.000A (2 x Marechal DS6 90amp 5p)
    1 MCCB 160amp 4p 18.000A (OUT 160amp) + 1 shunt release

    Rear5 x powerSYNTAX® 480amp L1-brown L2-black L3-grey N-blue PE-green 400V IP67 (IN ; power-lock 400A compatible)
    9 x CEE-17 32amp 5p 400V IP67 (OUT)
    2 x CEE-17 32amp 5p 400V IP67 (OUT)
    2 x Marechal DS6 90amp 5p IP65 (OUT)
    5 x powerSYNTAX® 480amp L1-brown L2-black L3-grey N-blue PE-green 400V IP67 with IP53 caps (OUT 160amp; powerlock 400A compatible)

    Technical dataCE Marking, IEC 61439-1 & 2 / PSC, Un : 400V 3pH+N+PE, fn : 50Hz, InA : 400amp, Icc : 10.000A, RDF : 71/100, IP : 54, Electrical insulation class : I (first)

  • Rear

    Rear

    Rear

  • Front

    Front

    Front

  • 400 Amp

    400 Amp

    Heavy Duty 2x12U

    Heavy Duty 2x12U

    Part Number: PBF400P212U-400

  • Rear

    Rear

    Rear

  • Front

    Front

    Front


  • Front1 voltmeter selector switch with analogic voltmeter + 1 set incoming leds
    1 MCCB 400amp 4p 36.000A (MAIN) with earth-leakage relay adjustable fault current and delay time + 1 shunt release + 1 E-STOP
    1 digital multimeter 96x96mm with LCD graphic display
    6 x RCBO 16amp 1pN-C 6.000A Idn=30mA AC (3 x SCHUKO 16amp 3p)
    2 x MCB 32amp 4p-C 6.000/10.000A with earth leakage add-on block Idn=30mA AC (2 x CEE-17 32amp 5p)
    2 x MCB 63amp 4p-C 6.000/10.000A with earth-leakage relay adjustable fault current and delay time (2 x CEE-17 63amp 5p)
    4 x MCB 125amp 4p-C 10.000A with earth-leakage relay adjustable fault current and delay time (4 x CEE-17 125amp 5p)

    Rear5 x powerSYNTAX® 480amp L1-brown L2-black L3-grey N-blue PE-green 400V IP67 (IN ; power-lock 400A compatible) with IP67 caps
    5 x powerSYNTAX® 480amp L1-brown L2-black L3-grey N-blue PE-green 400V IP67 (LOOP ; po-werlock 400A compatible) with IP67 caps
    6 x SCHUKO 16amp 3p 230V IP54 (OUT)
    2 x CEE-17 32amp 5p 400V IP67 (OUT)
    2 x CEE-17 63amp 5p 400V IP67 (OUT)
    4 x CEE-17 125amp 5p 400V IP67 (OUT)

    Technical dataCE Marking, IEC 61439-1 & 2 / PSC, Un : 400V 3pH+N+PE, fn : 50Hz, InA : 630amp, Icc : 10.000A, RDF : 50/100, IP : 44, Electrical insulation class : I (first)

  • 630Amp

    630Amp

    Heavy Duty 2x24U

    Heavy Duty 2x24U

    Part Number: PBF750P224U-630

  • Rear

    Rear

    Rear

  • Front

    Front

    Front


  • Front1 voltmeter selector switch with analogic voltmeter + 1 set incoming leds
    1 MCCB 630amp 4p 36.000A (MAIN) with earth-leakage relay adjustable fault current and delay time + 1 shunt release + 1 E-STOP
    1 digital multimeter 96x96mm with LCD graphic display
    3 x RCBO 16amp 1pN-C 6.000A Idn=30mA AC (3 x SCHUKO 16amp 3p)
    4 x MCB 32amp 4p-C 6.000/10.000A with earth leakage add-on block Idn=30mA AC (4 x CEE-17 32amp 5p)
    2 x MCB 63amp 4p-C 6.000/10.000A with earth-leakage relay adjustable fault current and delay time (2 x CEE-17 63amp 5p)
    5 x MCB 125amp 4p-C 10.000A with earth-leakage relay adjustable fault current and delay time (5 x CEE-17 125amp 5p)

    Rear5 x powerSYNTAX® 750amp L1-brown L2-black L3-grey N-blue PE-green 400V IP67 (IN ; power-lock 660A compatible) with IP67 caps
    5 x powerSYNTAX® 750amp L1-brown L2-black L3-grey N-blue PE-green 400V IP67 (LOOP ; powerlock 660A compatible) with IP67 caps
    3 x SCHUKO 16amp 3p 230V IP54 (OUT)
    4 x CEE-17 32amp 5p 400V IP67 (OUT)
    2 x CEE-17 63amp 5p 400V IP67 (OUT)
    5 x CEE-17 125amp 5p 400V IP67 (OUT)

    Technical dataTechnical data : CE Marking, IEC 61439-1 & 2 / PSC, Un : 400V 3pH+N+PE, fn : 50Hz, InA : 630amp, Icc : 10.000A, RDF : 50/100, IP : 44, Electrical insulation class : I (first)

  • A design tailored for your needs

    A design tailored
    for your needs

    A design tailored
    for your needs

    We'll build your bespoke distribution box according to your requirements. Choose model, dimensions, input, outputs, meters and safety switches. Let's shape your ideal layout together!

    We'll build your bespoke distribution box according to your requirements. Choose model, dimensions, input, outputs, meters and safety switches. Let's shape your ideal layout together!
