PowerBox 32amp Brick power distribution box

Brick Line

32 Amp versions

Brick Line

32 Amp versions

You'll never find such trustworthy bricks for your work. Our multiple sockets are solidly built and reliable. The right fit for your power distribution.

  • It will always be
    right there where you need it

    It will always be
    right there where you need it

    Easy to carry, power distribution on the go

    Easy to carry,
    power distribution on the go

    The PowerBox Brick units were created to be used either on the floor or hung up on a truss. They are light, practical and easily transportable thanks to their built-in handle. The containers are molded in in a special black hard rubber compound. Various models (Brick, Brick-S and Brick-Maxi) with different overall dimensions are available, so that each configuration will have its tailored size for its own combination of plugs, sockets and protections. On the versions with external power cables, cable glands with cable-saving spiral are provided to prevent breakage of the conductors due to bending and preserve the integrity of the cables over time. Input and outputs have their specific “voltage on” control lights. The switches are installed under IP54 hinged windows with automatic spring closing.

  • External box features

    External box features

    Excellent resistance to impacts
    Great electrical insulating qualities
    UV and ozone resistance
    Self-extinguishing and hardy flammable
    High mechanical strength
    Glow-wire-resistance 960°C according to EN 60695-2-11
    Mechanical impacts IK10 according to EN 50102

  • Versions and dimensions

    Versions and dimensions


    VersionHeightWidthDepth
    Brick72 mm430 mm115 mm
    Brick-S90 mm415 mm120 mm
    Brick-Maxi83 mm450 mm120 mm
  • Discover our popular solutions

    Discover our popular solutions

    Discover
    our popular solutions

    Or contact us to discuss a custom layout together

    Or contact us to discuss a
    custom layout together

    We know every job has its peculiar requirements and a few default products cannot fulfill everybody's needs. That's why we made customization the cornerstone of our work. Here we present some of our most successful Brick line layouts for you to choose or take inspiration from, in order to design your perfect configuration.

  • 32amp

    32amp

    Brick-S

    Brick-S

    Part Number: PBF32M4M1S

    Configuration1 CEE-17 32amp 3p 6h 230V IP44 (IN)
    4 x CEE-17 16amp 3p 6h 230V IP44 (OUT)
    1 RCBO 32amp 1pN-C IΔn 0,03A AC type (MAIN)
    2 x MCB 16amp 1pN-C (4 x CEE-17 16amp single-phase)

    Nominal dataIEC 61439-1 & 2, Ue=230V 1pH+N+E, fn=50Hz,InA=32amp, Icc=4.500A, IP=44, RDF=100%

     PowerBox Brick 32amp rubber distro - 4x CEE-17 OUT

  • 32 Amp

    32 Amp

    Brick-S

    Brick-S

    Part Number: PBF32P3M2S

    Configuration1 CEE-17 32amp 5p 6h 400V IP44 (IN)
    3 x CEE-17 32amp 3p 6h 230V IP44 (OUT)
    3 x RCBO 32amp 1pN-C IΔn 0,03A AC type (3 x CEE-17 32amp single-phase)

    Nominal dataIEC 61439-1 & 2, Ue=400V 3pH+N+E, fn=50Hz,InA=32amp, Icc=4.500A, IP=44, RDF=100%

     PowerBox Brick 32amp rubber distro - 3x CEE-17 OUT
  • PowerBox Brick 32amp rubber distro - 4x CEE-17 OUT

    32 Amp

    32 Amp

    Brick

    Brick

    Part Number: PBF32M4M1CC

    Configuration1 CEE-17 32amp 3p 6h 230V IP44 plug with 2m. cable type H07RN-F 3G6mm˛ (IN)
    4 x CEE-17 16amp 3p 6h 230V IP44 (OUT)
    1 RCBO 32amp 1pN-C IΔn 0,03A AC type (MAIN)
    2 x MCB 16amp 1pN-C (4 x CEE-17 16amp single-phase)

    Nominal dataIEC 61439-1 & 2, Ue=230V 1pH+N+E, fn=50Hz,InA=32amp, Icc=4.500A, IP=44, RDF=100%

  • 32amp

    32amp

    Brick-Maxi

    Brick-Maxi

    Part Number: PBF32P6M1SRC

    Configuration1 CEE-17 32amp 5p 6h 400V IP44 plug with 2m. cable type H07RN-F 5G6mm˛ (IN)
    6 x SCHUKO 16amp 3p 230V IP54 (OUT)
    1 RCCB 40amp 4p IΔn 0,03A AC type (MAIN)
    6 x MCB 16amp 1pN-C (6 x SCHUKO 16amp)

    Nominal dataIEC 61439-1 & 2, Ue=400V 3pH+N+E, fn=50Hz,InA=32amp, Icc=4.500A, IP=44, RDF=100%


     PowerBox Brick-Maxi 32amp rubber distro - 6x Schuko OUT

  • 32 Amp

    32 Amp

    Brick-Maxi

    Brick-Maxi

    Part Number: PBF32P6M1SRRC

    Configuration1 CEE-17 32amp 5p 6h 400V IP44 plug with 2m. cable  type H07RN-F 5G6mm˛ (IN)
    1 CEE-17 32amp 5p 6h 400V IP44 (LOOP)
    6 x SCHUKO 16amp 3p 230V IP54 (OUT)
    1 RCCB 40amp 4p IΔn 0,03A AC type (MAIN)
    6 x MCB 16amp 1pN-C (6 x SCHUKO 16amp)

    Nominal dataIEC 61439-1 & 2, Ue=400V 3pH+N+E, fn=50Hz,InA=32amp, Icc=4.500A, IP=44, RDF=50%

     PowerBox Brick-Maxi 32amp rubber distro - 6x Schuko OUT
  • A design tailored for your needs

    A design tailored
    for your needs

    A design tailored
    for your needs

    We'll build your bespoke distribution box according to your requirements. Choose model, dimensions, input, outputs, meters and safety switches. Let's shape your ideal layout together!

    We'll build your bespoke distribution box according to your requirements. Choose model, dimensions, input, outputs, meters and safety switches. Let's shape your ideal layout together!
